Nardi Pacific P — Italian-engineered portable high-pressure breathing air compressor from Nardi Compressori. The Pacific P is the fully-enclosed, heavy-duty portable in the Pacific line, built for fire service, first-responder, commercial diving, and industrial breathing-air work where the unit has to move between sites. It runs on an electric motor (Pacific P) or a gasoline engine (Pacific PG), and an integrated trolley is available for added mobility.
Select your Compressor Type above (Electric or Gasoline), then use the configurator on this page to choose model, operating pressure, connection type, voltage, and factory-installed options. The price updates as you configure.
Model lineup
Electric — Pacific P (five models)
- PACIFIC P 16 — 160 L/min (5.6 cfm), 3-stage, 3.0 kW, 230V single-phase
- PACIFIC P 23 — 230 L/min (8.1 cfm), 3-stage, 4.0 kW, three-phase
- PACIFIC P 27 — 270 L/min (9.5 cfm), 3-stage, 5.5 kW, three-phase
- PACIFIC P 30 — 300 L/min (10.6 cfm), 3-stage, 5.5 kW, three-phase
- PACIFIC P 35 — 350 L/min (12.4 cfm), 4-stage, 7.5 kW, three-phase
Gasoline — Pacific PG (four models)
- PACIFIC PG 23 — 230 L/min (8.1 cfm), 3-stage, 6.7 kW gasoline
- PACIFIC PG 27 — 270 L/min (9.5 cfm), 3-stage, 6.7 kW gasoline
- PACIFIC PG 30 — 300 L/min (10.6 cfm), 3-stage, 10 kW gasoline
- PACIFIC PG 35 — 350 L/min (12.4 cfm), 4-stage, 10 kW gasoline
Standard equipment (every Pacific P / PG)
- 330 bar / 4,700 psi maximum operating pressure
- PAC 1 purification system
- Fully enclosed protective carrying frame
- 4-fold filling device with 2 hose connections
- Splash lubrication (oil-pump lubrication optional on P 16/23/27 and PG 23/27)
- Compliant with DIN EN 12021 (European breathing-air standard)
Order-time configuration (selected above)
- Operating pressure: 225 bar / 3,200 psi or 330 bar / 4,700 psi. A 420 bar / 6,000 psi build is offered on the 4-stage models (P 35, PG 35); availability and pricing are confirmed at quote.
- Connection type (225 bar only): DIN, INT (YOKE), or DIN with reduction to INT-YOKE
- Voltage / frequency (Electric): 230V single-phase at 50 or 60 Hz on the P 16; three-phase models (P 23/27/30/35) support 230 / 400 / 440 / 480V at 50 or 60 Hz
Optional factory-installed equipment
All selectable in the configurator above; prices add to the base as you tick each item.
- Automatic system — Electric: electronic control panel with automatic condensate drain; Gasoline: automatic condensate drain, auto-stop, and electric start with key
- Soft start (230 L/min models and larger)
- Oil-pump lubrication (splash-lubricated models)
- Oil alert; hour meter
- Additional pressure or temperature sensors (Electric)
- PAC Filter 2 or PAC Filter 3 purification upgrade
- Double pressure (225 bar / 3,200 psi + 330 bar / 4,700 psi)
- Additional hose connections (max two), trolley, handles, large separators, 12 L eco-friendly condensate tank
See the Specifications tab for full technical specifications.
Replacement parts and consumables
The Pacific P ships with the PAC 1 purification tower as standard. Replace its cartridge per the schedule in your Operator's Manual — see the Nardi Filter PAC1 Replacement Filter Cartridge, and choose Electric (MC-AC media) for the electric Pacific P, or Gasoline / Diesel (MC-AC-HO with Hopcalite) for the gasoline Pacific PG. If your unit was ordered with a PAC 2 or PAC 3 tower upgrade, order the matching cartridge instead. Other Pacific consumables, hose-connection accessories, and service kits are sold separately — contact us for the correct reference.
Browse the full Nardi Compressori collection for other breathing-air, industrial, and oil-free compressors.
Engineered in Italy. Made in Italy.
| Specification | Electric (Pacific P) | Gasoline (Pacific PG) |
|---|---|---|
| Charging rate | 160 – 350 L/min (5.6 – 12.4 cfm) | 230 – 350 L/min (8.1 – 12.4 cfm) |
| Max operating pressure | 330 bar / 4,700 psi (420 bar option on 4-stage) | 330 bar / 4,700 psi (420 bar option on 4-stage) |
| Stages | 3 or 4 (model-dependent) | 3 or 4 (model-dependent) |
| Power | 3.0 – 7.5 kW | 6.7 – 10 kW |
| Power supply | 230V single-phase, or 230 / 400 / 440 / 480V three-phase | Gasoline engine |
| Purification system | PAC 1 | PAC 1 |
| Weight | 127 – 142 kg (280 – 313 lb) | 113 – 128 kg (249 – 282 lb) |
| Dimensions (L × W × H) | 120 × 54 × 67 cm | 120 × 54 × 67 cm |
| Country of origin | Italy | Italy |
| Compliance | DIN EN 12021, CE (CSA pending) | DIN EN 12021, CE (CSA pending) |
Brand: Nardi Compressori
Category: Breathing Air Compressor
SKU: NRD-PAC-P-ELEC
