Nardi Pacific CX, Italian-engineered high-output silenced vertical breathing air compressor from Nardi Compressori. The Pacific CX delivers 500 to 850 L/min and is built for high-throughput fill rooms, dive centers, fire and public-safety facilities, and industrial breathing-air operations. A sound-insulated cabinet with large wing-shaped fan blades keeps it exceptionally quiet and well ventilated, even in harsh environments.
Use the configurator above to choose model, operating pressure, connection type, voltage, purification system, and factory-installed options. The price updates as you configure.
Model lineup (four electric models)
- PACIFIC CX 50, 500 L/min (17.7 cfm), 3-stage, 11 kW, three-phase, single PAC 3
- PACIFIC CX 60, 600 L/min (21.2 cfm), 3-stage, 11 kW, three-phase, single PAC 3
- PACIFIC CX 68, 680 L/min (23.9 cfm), 4-stage, 15 kW, three-phase, Double PAC 3
- PACIFIC CX 85, 850 L/min (30 cfm), 4-stage, 18.5 kW, three-phase, Double PAC 3
Standard equipment (every Pacific CX)
- 330 bar / 4,786 psi maximum operating pressure
- Soft start, oil-pump lubrication, oil alert, and large separators, all standard
- Final-stage sensor fitted as standard
- Sound-insulated cabinet with large wing-shaped cooling fan
- Four filling hoses and a 12 L eco-friendly condensate collecting tank
- Single PAC 3 purification (CX 50 / CX 60) or Double PAC 3 (CX 68 / CX 85)
- Compliant with DIN EN 12021 (European breathing-air standard)
Order-time configuration (selected above)
- Operating pressure: 225 bar / 3,263 psi or 330 bar / 4,786 psi. A 420 bar / 6,092 psi build is offered on the CX 60, CX 68 and CX 85.
- Connection type (225 bar only): DIN, INT (YOKE), or DIN with reduction to INT-YOKE
- Voltage / frequency: 208V, 480V or 600V three phase at 60 Hz. Other voltages are available on request.
- Purification system: CX 50 and CX 60 ship with a single PAC 3 tower and can add the supplementary 2 x PAC 3 system; CX 68 and CX 85 ship with Double PAC 3 as standard
Optional factory-installed equipment
- Additional pressure or temperature sensors, one for each stage before the final stage (two on the CX 50 and CX 60, three on the CX 68 and CX 85)
- Supplementary filtering (2 x PAC 3) on the CX 50 and CX 60
- Double pressure (225 bar / 3,263 psi + 330 bar / 4,786 psi)
- ATEX certificate, Zone II
- Touch screen control panel
See the Specifications tab for full technical specifications.
Replacement parts and consumables
The Pacific CX uses the PAC 3 purification tower (two of them on the CX 68 and CX 85). Replace each cartridge per the schedule in your Operator's Manual, see the Nardi Filter PAC3 Replacement Filter Cartridge. Double PAC 3 units take two PAC 3 cartridges. Other Pacific consumables and service kits are sold separately, contact us for the correct reference.
Browse the full Nardi Compressori collection for other breathing-air, industrial, and oil-free compressors.
Engineered in Italy. Made in Italy.
| Specification | Pacific CX (electric) |
|---|---|
| Charging rate | 500 – 850 L/min (17.7 – 30 cfm) |
| Max operating pressure | 330 bar / 4,786 psi (420 bar / 6,092 psi option on the CX 60, CX 68 and CX 85) |
| Stages | 3 (CX 68 / CX 85: 4) |
| Power | 11 – 18.5 kW |
| Power supply | 208V, 480V or 600V three phase, 60 Hz. Other voltages available on request. |
| Purification system | Single PAC 3 (CX 50 / 60); Double PAC 3 (CX 68 / 85) |
| Weight (estimated) | 400 – 570 kg (882 – 1,257 lb) |
| Dimensions (L × W × H) | 84 × 75 × 142 cm |
| Country of origin | Italy |
| Compliance | DIN EN 12021, CE (CSA pending) |
Brand: Nardi Compressori
Category: Breathing Air Compressor
SKU: NRD-PAC-CX-ELEC
